Model Number:531X304IBDASG1
Manufacturer:GE
Compatibility:For GE‘s AC2000 System
Board Components:Transformer, Vertical Pin Header Connector, Two Parallel Heat Sinks, Jumper Switches, Transistors, Resistors, Resistor Network Arrays, Capacitors, Diodes
Code:006/09 and C-ess
Dimensions:To be confirmed from specific documentation
Mounting Holes:Drilled into the corners
Interior Slots:Built into the interior of the board
The GE 531X304IBDASG1 is a meticulously designed Base Drive Card engineered to seamlessly integrate with the GE AC2000 system.
It features a robust design with three common sections, each equipped with essential components such as transformers, vertical pin header connectors, and parallel heat sinks.
These components work together to optimize performance and ensure reliable operation under demanding conditions.
The card also includes jumper switches that can be adjusted to different positions, offering flexibility in configuration.
The inclusion of transistors, resistors, and capacitor networks enhances the card’s ability to manage electrical signals efficiently.
Its compact yet sturdy construction allows for easy installation and maintenance, making it an indispensable component in industrial automation setups.
