Model Number:PXI-5650
Bandwidth:Up to 6 GHz
Frequency Resolution:0.01 Hz
Output Power Range:-120 dBm to +13 dBm
Phase Noise:-105 dBc/Hz at 10 kHz offset
Interface:PXI Express
Clock Frequency:10 MHz
Power Supply:9 V to 30 V DC
Dimensions:133 mm x 130 mm x 56 mm (W x D x H)
The NI PXI-5650 RF Signal Generator is engineered for precision and reliability in demanding test environments. With its wide frequency range from 10 MHz to 6 GHz, it covers a broad spectrum of applications in telecommunications and defense. This model provides up to 25 dBm of output power, making it suitable for a variety of signal strength requirements. The low phase noise ensures minimal interference and superior signal quality, crucial for accurate testing. Its advanced modulation capabilities allow for complex signal generation, supporting up to 50 MHz bandwidth. Designed with the latest in RF technology, this signal generator integrates seamlessly into PXI systems, enhancing the capabilities of your test setup. Ideal for engineers and researchers seeking high-performance solutions for signal testing and validation.
